| Switching capacity |
52 Gbit/s |
| Packet forwarding rate |
38.69 Mpps |
| GE RJ45 |
24 (PoE+) (1G/100M/10M) |
| PoE |
Supported |
| Maximum PoE power consumption [W] |
124 |
| Certification |
EMC certification Safety certification Manufacturing certification |
| Chassis material |
Metal |
| Static power consumption [W] |
13 |
| Dimensions without packaging (H x W x D) [mm(in.)] |
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 260.0 mm (1.72 in. x 17.40 in. x 10.24 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 267.0 mm (1.72 in. x 17.40 in. x 10.51 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] |
90.0 mm x 555.0 mm x 400.0 mm (3.54 in. x 21.85 in. x 15.75 in.) |
| Installation type |
Rack mounting,Desk mounting,Wall mounting |
| Weight without packaging [kg(lb)] |
3.2 kg (7.1 lb) |
| Weight with packaging [kg(lb)] |
3.7 kg (8.16 lb) |
| Typical power consumption [W] |
24 |
| Maximum power consumption [W] |
Without PoE: 24 W Full PoE load: 165 W (PoE: 124 W) |
| Long-term operating temperature [°C(°F)] |
0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Long-term operating relative humidity [RH] |
5% RH to 95% RH, non-condensing |
| Power supply mode |
AC built-in |
| Input voltage range [V] |
AC input: 90 V AC to 300 V AC; 47 Hz to 63 Hz |
| Power supply surge protection [kV] |
Differential mode: ±6 kV; common mode: ±6 kV |
| Heat dissipation mode |
Natural heat dissipation |
